Wharfedale’s new EVO4 has grown out of the extensive research and development that produced the ELYSIAN flagship loudspeakers and borrows much of the technology involved in ELYSIAN.

The primary focus is on the AMT development resulting in a radically different way of reproducing high frequency detail efficiently and accurately. Similar cabinet technology to ELYSIAN provides a stable and solid foundation for the drive units with radiused edges to help integrate the driver output with the room acoustics. In addition the unique SLPP bass reflex system, as developed for ELYSIAN, is now incorporated in EVO4.

General Description:
3-way bookshelf speakerEnclosure Typebass reflexTransducer Complement3-wayBass Driver6.5″(165mm) black woven Kevlar® coneMidrange Driver2″(50mm) soft domeTreble Driver30x60mm AMTAV ShieldNoSensitivity (2.83V @ 1M)87dBRecommended Amplifier Power25-120WPeak SPL105dBNominal Impedance8Ω CompatibleMinimum Impedance4ΩFrequency Response (+/-3dB)54Hz ~ 22kHzBass Extension (-6dB)48HzCrossover Frequency1.4kHz,3.9kHzDimensions (HxWxD)455 x 250 x (340+10)mmNet Weight13.4kg/pcs
